Hey guys,

Does anyone have an ATI damper tool they would be able to rent out for a few days? I don't mind giving a deposit and a few bucks to offer as well. I rarely work on engines that have aftermarket dampers.

Thank you

2004LB7

2004LB7

Well-known member
Dec 15, 2010
6,982
2,145
113
Norcal
If you are trying to remove it, you can always go down this route

www.duramaxdiesels.com

Harmonic balancer puller for 6.6

So I'm sure I'm not the only one who has worked behind some one who didn't quite get the balancer square on pin and proceeded to beat it on. Well after my third one this month I got fed up and made this. It's kinda crude, wanted to see that it worked first. Since there's no good place to pull...
www.duramaxdiesels.com www.duramaxdiesels.com

1FastBrick

1FastBrick

Well-known member
Dec 1, 2016
2,541
1,069
113
Junkyard
Animals1234 said:
Yes
Click to expand...
I think I have the Generic version of this tool But it's at another property. I am in Orange County I could probally help you with this. Basically it's this set in a grey case instead of red. The Kit is made by Proform.

a Quick search shows harbor freight is offering under the Madox name brand


This is the ATI Specific Version.


Harbor freight version.

www.harborfreight.com

Harmonic Balancer Puller/Installer Set, 52 Piece

Amazing deals on this Harmonic Balancer Puller/Installer Set at Harbor Freight. Quality tools & low prices.
www.harborfreight.com www.harborfreight.com

A

Animals1234

Active member
Jun 8, 2017
143
44
28
I was told by someone that the ATI Dampers needed their specific tool. Let me try that generic tool kit from harbor freight and see if it can get pulled with that. $80 bucks for a tool versus $230 seems ok to try with me

  • Like
Reactions: wydopenLb7 and 1FastBrick
1FastBrick

1FastBrick

Well-known member
Dec 1, 2016
2,541
1,069
113
Junkyard
Animals1234 said:
I was told by someone that the ATI Dampers needed their specific tool. Let me try that generic tool kit from harbor freight and see if it can get pulled with that. $80 bucks for a tool versus $230 seems ok to try with me
Click to expand...
That's why I Purchased the ProForm Version. comes with more of a verity of bolts.

The only thing is the Dmax Might require a different crank thread adapter that may not be in the generic kit.

1FastBrick

1FastBrick

Well-known member
Dec 1, 2016
2,541
1,069
113
Junkyard
They don't want you using the sloppy cast units that can deform under extreme pressure.

Do you see a Specific Difference in the tool itself that Makes the ATI Better and worth the additional money?

ATI Damper tool.JPGJegs Generic tool.JPGHarbor freight generic tool.JPG

1FastBrick

1FastBrick

Well-known member
Dec 1, 2016
2,541
1,069
113
Junkyard
If you can not locate the tool locally, I can bring mine home with me tomorrow.
I just don't know if there is a thread adapter that will work in the kit for a Dmax.

It may not be needed though if you are only removing a balancer.

Dozerboy

Dozerboy

Well-known member
Jun 23, 2009
4,892
470
83
TX of course
From the sound of it damper can be pretty hard to remove. Some even destroying it if I remember correctly. I wonder if a induction heater could be used and not damage the front seal?

1FastBrick

1FastBrick

Well-known member
Dec 1, 2016
2,541
1,069
113
Junkyard
This is the Performance Tool set i bought. For some reason I was thinking pro form...

Any way. For installation of an ATI ballancer, I would need that DMax specific stud I posted earlier... it doesn't even come in the ATI version of this tool. I verified none of the ones in this kit are long enough or the correct thread for a Dmax crank.
